Xaar 1201 printhead UV Led Printer

YOTTA YD-F2513Xa UV LED flatbed printer adopts the new developed XAAR 1201 print head.

Why choose XAAR 1201 Printhead?

1. Best-in-class print quality The new Xaar 1201 delivers a high print quality superior to other printheads in its class. • 8 grey levels at 600 npi give an apparent resolution better than 1440 dpi • Two printheads can be mounted inline to create an economical 4 colour printer delivering 600 npi native resolution per colour • Alternatively with just four printheads, OEMs can design printers with 1200 npi by 1200 npi native resolution • The small drop size of 2.5 pL delivers the best combination of throughput and print quality for arange of applications. Variable drop size allows small drops for ultra-close viewing and large drops for long distance viewing

2. Highly versatile The new Xaar 1201 incorporates a number of features which make it an extremely versatile printhead for banners and Point of Sale (POS) applications. • Capable of printing 1, 2 or 4 colours per printhead • Can be configured to print 4 colours at 300 npi or 2 colours at 600 npi depending on the price-point and end user profile that OEMs wish to target

• Two pairs of interleaved rows means that OEMs have a choice of native resolution – the default resolution when running 4 colours is 300 npi. Running 2 colours per printhead takes advantage of the nozzle row pair pre-alignment to achieve 600 npi per colour

Advantages of YD-F2513Xa Xaar uv flatbed printer

Printing size: 2500*1300mm (8ft x 4ft)

Print head: Xaar 1201 (it is launched in year of 2016)

Print thickness: max 400mm

Print speed: 15sqm to 30sqm per hour (double rows with CMYK)

Head quantity: 1-8 Xaar available

With the feature of one head can hold 1,2 or 4 kinds of color, this uv flatbed printer YD-F2513Xa create in a affordable and cost-effective price. 2.5pl droplt delivers ultra-exquisite image in various kinds of medias, especially suitable for logo printing, phone case printing, handicrafts printing as well ceramic tiles, crystal etc.

With the unique printing thickness 400mm, this machine is very popular in printing book of edges, wine box, wood box, gift box, and various kinds of materials.
